Product Details
Place of Origin: China
Brand Name: E-link
Certification: CE
Model Number: LNK-U4TF1-2.0
Payment & Shipping Terms
Minimum Order Quantity: 1pairs
Price: USD129/PCS
Packaging Details: USB 2.0 Fiber Optic Extender Standard Carton Packaging
Delivery Time: 7-10 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, PayPal
Supply Ability: 1000000PCS/Month
Connector: |
Simplex LC |
Wave Length: |
1310nm/1550nm |
Max. Distance: |
6KM |
USB2.0: |
Type-A Female |
Power: |
5V DC |
N.W.: |
0.75Kg |
Connector: |
Simplex LC |
Wave Length: |
1310nm/1550nm |
Max. Distance: |
6KM |
USB2.0: |
Type-A Female |
Power: |
5V DC |
N.W.: |
0.75Kg |
4-port USB 2.0 Fiber Optic Extender, including SFP moudules
USB 2.0 Fiber Optic Extender Advantages:
Cat5 network cable 100 meter, Cat6 network cable 170 meters;
Support USB2.0 high-speed (High-Speed), full-speed (Full-Speed) or low-speed (Low-Speed) device;
Support optical fiber extension of 6km, of which USB non-real-time transmission can reach more than 10km;
Application
E-link 4 Port USB 2.0 Fiber/UTP Optic Extender realizes the extension of USB signal more than 100 Meter through the network
cable. The use of optical fiber cable can extend the distance up to 6KM.
Ordering Information
| Model | Description |
| LNK-U4TF1-2.0 | 4-port USB 2.0 Fiber/UTP extender, 1 USB for Local Unit, 4 USB for Remote Unit, up to 6KM via Single Mode fiber cable, up to 170m via Cat6 cable |
Technical Indexes
| Optical | Connector | Simplex LC |
| Wave length | 1310nm/1550nm | |
| Max. Distance | 6KM | |
| USB2.0 | Input/Output | USB2.0 Type-A Female |
| Physical | Size (L× W ×H) | 117mm x104mm x28mm |
| Case | Aluminum | |
| Color | Black | |
| N.W. | 0.75Kg | |
| Power | Voltage | 5V DC |
| Power consumption | <5W | |
| Environment | Working temperature | -20℃~70℃ |
| Storage temperature | -40~85℃ | |
| Humidity | 0-95% (non-condensing) |
