Product Details
Place of Origin: China
Brand Name: E-link
Certification: ROHS,FCC,CE
Model Number: LNK-POE202
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: PoE Injector Adapter Standard Export Package
Delivery Time: 5-12 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1000 pcs/month
Keyword: |
PoE Power Supply |
Input Power: |
100-240V AC |
Standard: |
IEEE802.3af/at |
Mounting Options: |
Desktop |
Weight: |
0.25Kg |
Casing: |
Plastic Case |
Keyword: |
PoE Power Supply |
Input Power: |
100-240V AC |
Standard: |
IEEE802.3af/at |
Mounting Options: |
Desktop |
Weight: |
0.25Kg |
Casing: |
Plastic Case |
2-Port POE Adapter Injector
PoE Adapter Advantages
► Up to 15.4W/25.5W of PoE Power
► Fully IEEE802.3af/IEEE802.3at compliant
► Supports 10/100M or 10/100/1000M LAN environment
► Plug & Play
► No configuration required
► Reduced Installation cost
► Safe and Reliable Power to WLAN Access Points
► Automatic Detection and Protection of Non–standard Ethernet Terminals
Technical Indexes
| Parameter | Specifications |
| Features |
• Conforms to IEEE802.3af standard RJ-45 • Conforms to IEEE802.3af standard RJ-45 |
|
• Data Input Interface RJ-45 10/100Base-TX/ • Data Input Interface RJ-45 10/100/1000Base-TX |
|
| • Output Port Power Cable Included | |
| Data Rate |
10/100Mbps 10/100/1000Mbps |
|
Input Power |
AC100-240V |
| Output Power |
15.4W Max IEEE802.3af 30W Max IEEE802.3at |
| Wiring | • Data provide over pairs 1/2(+) and 3/6(-) |
| • Power over spare pairs 4/5(+) and 7/8(-) | |
| Output type |
Single outputa 2*RJ45 connector ---POE 2*RJ45 connector ----LAN |
| LED Display | YES |
| Operating Temperature | 0 to +40°C, |
| Humidity | Max. 95% RH(non-condensing) |
| Dimension | 170*98*42mm (H×D×W) |
| Weight | 250g |
Overview
The LNK-POE202/LNK-POE302 Power over Ethernet (PoE) adapter is designed to supply operational power to surveillance cameras and wireless LAN devices such as access points, bridges and routers. It enables power current to travel on the Ethernet network cable, thus eliminates the need to directly connect a power supply to the wireless LAN device. Power and Data are combined on a single cable, thus eliminating the need for extra power lines and also reducing installation costs and manpower.
Ordering Information
| Model | Decription |
| LNK-POE202 | 2-Port PoE Adapter, 10/100Mbps, IEEE 802.3af 15.4W |
| LNK-POE202AT | 2-Port PoE Adapter, 10/100Mbps, IEEE 802.3at 30W |
| LNK-POE302 | 2-Port PoE Adapter, 10/100/1000Mbps, IEEE 802.3af 15.4W |
| LNK-POE302AT | 2-Port PoE Adapter, 10/100/1000Mbps, IEEE 802.3at 30W |
