Product Details
Place of Origin: China
Brand Name: E-link
Certification: CE
Model Number: LNK-1100P
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: USD29/PCS
Packaging Details: Micro Mini SFP Media Converter Standard Carton Packaging
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, PayPal
Supply Ability: 1000000PCS/Month
Power Consumption: |
<3W |
Temperature: |
0~50ºC (Operating); -20~70ºC (Storage) |
Humidity: |
5% ~ 90% Non-condensing |
Dimension: |
94x71x26mm (WxDxH) |
Power Consumption: |
<3W |
Temperature: |
0~50ºC (Operating); -20~70ºC (Storage) |
Humidity: |
5% ~ 90% Non-condensing |
Dimension: |
94x71x26mm (WxDxH) |
Fast Ethernet 10Mbps 100Mbps PoE PSE Fiber Media Converter All In One
10/100Mbps Fast Ethernet PoE-PSE Fiber Media Converter
Advantages:
► 10/100Base-TX to 100Base-X Fiber
► Fiber to copper Ethernet converter and PoE injector all in one device
► Extend network distances up to 120km
► Supply PSE power to PoE and PoE+ compliant devices
► IEEE 802.3af and IEEE802.3at compliant
► Provide 15.4 to 30 Watts of PoE power
► IEEE802.3af with max. Power 15.4 W, IEEE802.3at with max. Power 30W.
Technical Indexes
| Parameter | Specifications |
| Standard | IEEE802.3i 10Base-T; |
| IEEE802.3u 100Base-TX; | |
| IEEE802.3 100Base-FX; | |
| IEEE802.3x Flow Control; | |
| IEEE802.3af/at Power over Ethernet | |
| Fiber Type | Multi-mode (MM): 50/125μm, 62.5/125μm |
| Single mode (SM): 9/125μm | |
| Power over Ethernet | IEEE 802.3af/at Power over Ethernet |
|
IEEE 802.3af: PoE 48V DC, max. 15.4 watts, 350mA IEEE 802.3at: PoE 48~56V DC, max. 30 watts, 650mA |
|
| Power Pin Assignment: 4/5(+), 7/8(-) | |
|
Distance |
Multi-mode: 2 km; |
| Single Mode: 20/40/60/80/100/120km; | |
| Single fiber single mode: 20/40/60/80/100 km | |
| Category-5 twisted pairs: 100m | |
| Date Rate | 10/100Mpbs |
| Connector | RJ45, SC |
| Wavelength | 1310nm, 1550nm |
| Diagnostic LED | Power, Link/Activity |
| Power | DC48V, 1.25A |
| Power Consumption | <3W |
| Temperature | 0~50ºC (Operating); -20~70ºC (Storage) |
| Humidity | 5% ~ 90% non-condensing |
| Dimension | 94x71x26mm (WxDxH) |
Overview
E-link's feature rich PoE Media Converters transparently connect copper to fiber while providing Power over Ethernet ( PoE ) to standards-based PoE and PoE+ compliant devices such as IP cameras, VoIP phones and wireless access points.
E-link LNK-1100P series media converters are 10/100BaseT/TX to 100BaseFX Power over Ethernet (PoE) devices that serve as Power Sourcing Equipment (PSE),which allows the converter to provide power to IEEE802.3af /at PoE standard-compliant Powered Devices (PDs) using the twisted pair connection. Power transmitted along with data in one single cable (RJ45) allows you to expand your network where there are no power lines or outlets, where you wish to fix devices such as Wifi -Aps, IP Cameras or IP Phones, etc.
Ordering Information
| Model | Description |
| LNK-1100P | 1xRJ45, 1xSC, 10/100Mbps, IEEE802.3af, POE power: 15.4W, MM Dual Fiber, 2KM |
| LNK-1100P-20 | 1xRJ45, 1xSC, 10/100Mbps, IEEE802.3af, POE power: 15.4W, SM Dual Fiber, 20KM |
| LNK-1100PT | 1xRJ45, 1xSC, 10/100Mbps, IEEE802.3at, POE+ power: 25.5W, MM Dual Fiber, 2KM |
| LNK-1100PT-20 | 1xRJ45, 1xSC, 10/100Mbps, IEEE802.3at, POE+ power: 25.5W, SM Dual Fiber, 20KM |
