Product Details
Place of Origin: China
Brand Name: E-link
Certification: ISO9001 / CE / RoHS / FCC
Model Number: LNK-FVGA-KVM
Payment & Shipping Terms
Minimum Order Quantity: 1pair
Price: Negotiate
Packaging Details: Fiber Media Convertor Standard Carton Packaging
Delivery Time: 1-3working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, PayPal
Supply Ability: 1000000PCS/Month
Power Supply: |
The Power Adapter: DC 5V/2A |
Power Dissipation: |
MAX 6W |
Working Temperature: |
-5℃ ~ +70℃ |
Humidity: |
Operating: 5% ~ 90% |
Dimension: |
155*115*30mm |
The Warranty: |
1 Year Free Warranty, Life-long Maintenance |
Power Supply: |
The Power Adapter: DC 5V/2A |
Power Dissipation: |
MAX 6W |
Working Temperature: |
-5℃ ~ +70℃ |
Humidity: |
Operating: 5% ~ 90% |
Dimension: |
155*115*30mm |
The Warranty: |
1 Year Free Warranty, Life-long Maintenance |
USB VGA KVM Fiber Optic Extender Support keyboard and
mouse signal transmission
Fiber Optic Accessories Advantages:
► Transmits VGA video signals up to 10km over one fiber optic cable;
► Support video resolution up to 1920*1080P@60Hz;
► Support keyboard and mouse signal transmission;
► Support external stereo audio unidirectional transmission;
► Support transmitter one channel signal output;
► Support RS232 signal unidirectional transmission, baud rate self-adaptive;
► High compatibility, can auto-match source and display device;
► Built-in automatic adjustment system, make the image smooth, clear and stable;
► Built-in ESD protection system;
► Simple to install, plug and play;
The LNK-FVGA-KVM Fiber optic extender provides extension of VGA signals long distances
transmission over one fiber optic cable, it supports high resolution up to 1080P, KVM,
transmitter local output, RS232 signal and external audio transmission function. The
extender can use for a wide range of applications that requiring long distance transmission
of high resolution with high quality by its good stability and powerful security.
Application
Technical Parameters
| Parameter | Description | |
| Video | Standards | VGA |
| Maximum pixel clock | 380MHz | |
| Resolution |
1920x1200@60Hz / 1920x1080@60Hz 1600x1200@60Hz / 1680x1050@60Hz 1280x1024@60Hz / 1280x1024@75Hz 1280x800@60Hz / 1280x768@60Hz 1280x720@60Hz / 1024x768@60Hz 1024x768@75Hz / 800x600@60Hz/75Hz |
|
| Impedance | 75Ω | |
| Audio | Interface | 3.5mm earphone seat |
| Format | 44.1K,48K,96K,176K,192K | |
| Signal type | Stereo | |
| K/M | Interface |
To PC: MINI-USB To keyboard and mouse: USB-A |
| RS232 | Interface | Industrial terminal |
| Signal direction | Bidirectional | |
| Baud rate | Self-adaptive, Max:115200bps | |
| Data bits | 8 | |
| Optical fiber | Interface | LC connector |
| Fiber type | Single-mode single fiber | |
| Wavelength | Single-mode 1310nm | |
| Interface bandwidth | 2.97Gbps | |
| Transmission distance | standard 10km | |
| Other | Power supply | The power adapter: DC 5V/2A |
| Power dissipation | MAX 6W | |
| Temperature | Operating: -5℃ ~ +70℃ | |
| Humidity | Operating: 5% ~ 90% | |
| Dimension | 155*115*30mm | |
| The warranty | 1 year free warranty, life-long maintenance | |
Panel
Transmitter
Receiver
Odering Information
| Model | Details |
| LNK-FVGA-KVM -T | 1080P VGA KVM Fiber Optic Extender Transmitter |
| LNK-FVGA-KVM -R | 1080P VGA KVM Fiber Optic Extender Receiver |
