2.5Gb/s 20km SFP Transceiver (Multi-rate)Hot Pluggable, Duplex LC, +3.3V,
1310nm, DFB-LD, Single-mode, DDM
Fiber Optic Accessories Advantages:
The transceiver consists of three sections: a 850nm VCSEL laser transmitter, a PIN photodiode
integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy
class I laser safety requirements.
The transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement
(MSA)1. They are compatible with Fiber Channel per FC-PI-2 Rev. 10.0. also simultaneously
compatible with Gigabit Ethernet as specified in IEEE Std 802.3.
Module Block Diagram
Application
Technical Parameters
| Parameter | Symbol | Min | Typical | Max | Unit | Notes | ||
| Transmitter | ||||||||
| Date Rate | 4.25 | Gb/S | ||||||
| Centre Wavelength | λc | 830 | 860 | nm | ||||
| Spectral Width (RMS) | ∆λ | 1 | nm | |||||
| Average Output Power (BOL) | Pout | -9 | -2.5 | dBm | 1 | |||
| Extinction Ratio | ER | 5 | dB | |||||
|
Average Launch Power-OFF Transmitter |
Pout | -4.5 | dBm | |||||
| Optical Eye Diagram | Fiber Channel Compliant | |||||||
| Optical Rise/Fall Time(20%~80%) | tr/tf | 120 | ns | |||||
| Data Input Swing Differential | VIN | 300 | 1800 | mV | 2 | |||
| Input Differential Impedance | ZIN | 90 | 100 | 110 | Ω | |||
| TX Disable | Disable | 2.0 | Vcc | V | ||||
| Enable | 0 | 0.8 | V | |||||
| TX Fault | Fault | 2.0 | Vcc | V | ||||
| Normal | 0 | 0.8 | V | |||||
| Receiver | ||||||||
| Centre Wavelength | λc | 830 | 860 | nm | ||||
| Receiver Sensitivity (BOL) | -15 | dBm | 3 | |||||
| Receiver Overload | 0 | dBm | 3 | |||||
| LOS De-Assert | LOSD | -20 | dBm | |||||
| LOS Assert | LOSA | -25 | dBm | |||||
| LOS Hysteresis | 0.5 | 6 | dB | |||||
| Receiver Reflectance | -20 | dB | ||||||
| Data Output Swing Differential | Vout | 350 | 1800 | mV | 4 | |||
| Loss of Signal (LOS) Assert Time | TAssert | 500 | nS | |||||
| Loss of Signal (LOS) DeassertTime | TDeassert | 500 | nS | |||||
| LOS | High | 2.0 | Vcc | V | ||||
| Low | 0 | 0.8 | V | |||||
