Product Details
Place of Origin: China
Brand Name: E-link
Certification: ROHS,FCC,CE
Model Number: LNK-FS800M
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: Ethernet Switch Standard Export Package
Delivery Time: 5-12 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1000 pcs/month
Keyword: |
9-ports Managed Fiber Switch |
Fiber Ports: |
8 100Mbps SFP Ports |
Combo Port: |
1000M SFP&10/100/1000M RJ45 |
Power: |
DC12V/2A (DC12-48V) |
Working Temperature: |
-10~60℃ |
Dimension: |
28mm (H)×193mm(W)×119mm (D) |
Keyword: |
9-ports Managed Fiber Switch |
Fiber Ports: |
8 100Mbps SFP Ports |
Combo Port: |
1000M SFP&10/100/1000M RJ45 |
Power: |
DC12V/2A (DC12-48V) |
Working Temperature: |
-10~60℃ |
Dimension: |
28mm (H)×193mm(W)×119mm (D) |
DC12V 2A Uplink Managed Fiber Switch 8x100M SFP Ports 1x1000M SFP Port
8x100M SFP ports + 1x1000M SFP port /TP port (Combo) uplink Managed Fiber Switch
Ethernet Fiber Switch Advantages
► support maximum 8 SFP fiber ports and 1 GE Combo port (SFP fiber port/RJ45 port interchange)
► Support each port full rate, full-duplex non-blocking forwarding
► Support 8K MAC learning, 1Mbit storage and forward cache space, 4.6G back plane bandwidth
► Supports to substitute central fiber converter, simplify network structure, lower network establishing cost, reduce device fault
► All optic ports, strengthen the an-interference ability
Managed Network Switch Technical Indexes
|
Standard |
IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.1d Spanning Tree |
|
Wavelength |
850nm/1310nm/1550nm |
|
Distance |
100M SFP: Depending on SFP Module Cat5:100m |
|
Port |
8 SFP fiber ports: 100Mbps 1 Gigabit Combo port:1 Gbps, 1000M SFP&10/100/1000M RJ45 |
|
MAC |
8K |
|
Bit error rate |
<1/1000000000 |
|
MTBF |
100000 hours |
|
Power |
DC12V/2A (DC12-48V) |
|
Power consumption |
10W |
|
Working temperature |
-10~60℃ |
|
Storage temperature |
-40~80℃ |
9-Port 100M Fiber Switch Overview
E-link LNK-FS800M is a nine ports managed 100M all optic fiber switch. It offers eight SFP fiber ports access and one Gigabit Combo port (1000M SFP port and 10/100/1000M adaptive RJ45 Ethernet interchange) uplink. LNK-FS800 supports SFP modules hot plug, and supports to work with fiber switches, fiber converters and other devices witch fiber ports. It supports WEB management as a managed switch; It applies to security system, electric system, traffic system requirements.
Optical Fiber Switch Hub Ordering Information
|
Model |
Description |
|
LNK-FS800M |
9-ports Managed Fiber Switch: 8x100M SFP ports + 1x1000M SFP port (Combo) uplink + 1x10/100/1000M RJ45 TP port (Combo) uplink, SFP slot supports 100BASE-SFP, not include SFP modules, External Power DC12V, supports WEB management |
