Product Details
Place of Origin: China
Brand Name: E-link
Certification: ROHS,FCC,CE
Model Number: LNK-3GSDI-4BV
Payment & Shipping Terms
Minimum Order Quantity: 1 pair
Price: negotiation
Packaging Details: SDI Fiber Extender Standard Export Package
Delivery Time: 5-12 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1000 pairs/month
Keyword: |
3G-SDI Fiber Extender |
Transmission Distance: |
550m-20Km |
Video Input/output Voltage: |
Typical:1Vpp, Min 0.5Vpp, Max 1.5Vpp |
Video Bits Rate: |
Max 3.2Gb/s |
Dimensions (LxWxH): |
19inch 1U (483 X 220 X 44.45mm ) |
Keyword: |
3G-SDI Fiber Extender |
Transmission Distance: |
550m-20Km |
Video Input/output Voltage: |
Typical:1Vpp, Min 0.5Vpp, Max 1.5Vpp |
Video Bits Rate: |
Max 3.2Gb/s |
Dimensions (LxWxH): |
19inch 1U (483 X 220 X 44.45mm ) |
4-Channel Bidirectional 3G-SDI Fiber Converter
Overview
LNK-3GSDI-4BV Series supports 4-channel bidirectional 3G-SDI standard high-definition video signal transmitted via single fiber optical cable, and monitor the signal locally over a 3G/HD-SDI loop output. E-link 3G-SDI Video over Fiber Converters includes one transmitter and one receiver for 1080P 3G-SDI signal. E-link 3G-SDI Fiber Converters can simultaneously transmit 4-Ch bidirectional 3G-SDI Video, 1-Ch Reverse RS-485 data, signal through a single optical fiber. The video quality up to broadcast standard, audio quality up to CD level supports Reverse RS-485 data communication format.
3G-SDI Fiber Extender Advantages
► 4 channel bidirectional 3G-SDI video transmission over optic fiber
► Automatic cable equalization to ensure signal integrity
► Automatic re-clocking 270Mbit/s - 1.48Gbit/s - 3Gbit/s
► Directly compatible with 3G-SDI camera systems and support Reverse RS-485 data protocols
► Long transmission capability at least 10 km (6.2miles) , up to 120 km
► Terminal block power input for industrial application
► Supports hot swapping and hot plugging
► Full digital non-compression broadcast level transmission;
► super optic dynamic range and free of adjustment prior to use;
► fiber optic WDM/CWDM/DWDM technique;
► industry level ultra-broad temperature range (-40℃~+85℃), adaptable to various environments;
3G SDI Fiber Converter Technical Indexes
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SDI to Fiber Converter Ordering Information
| Model | Description |
| LNK-3GSDI-4BV | 4-Ch Bidirectional 3G-SDI Video with loop-out, 20km, SM, FC, including 1 transmitter & 1 receiver, used by pairs |
| LNK-3GSDI-4BV1R | 4-Ch Bidirectional SDI Video with loop-out + 1-Ch RS485 Reverse Data, 20km, SM, FC, including 1 transmitter & 1 receiver, used by pairs |
